If you prefer the indicator to be part of the bike's body, the Puig integrated turn signal kit is your best option. Turn signals integrated into the fairing of the motorcycle and available in four different models for Honda, Kawasaki, Suzuki and Yamaha manufacturers.

Technical information It should be noted that most motorcycles use bimetallic relays, so their frequency depends directly on the amperage that circulates through the circuit. When replacing them, this amperage varies, and therefore the frequency of blinking does also.

In case of using electronic relays, whose frequency does not depend on the amperage, it should not affect flicker. In case we have doubts about the relay that our motorcycle uses, it is advisable to mount the indicator and check the frequency.

The turn signal bulb should also be taken into account, in case the bulb's power varies we must replace it with one of the same power and it can be found in our catalog. If our choice is to use an LED bulb, there are two options to balance the blink frequency: One resistance must be incorporated in parallel in the circuit of the right side and another one in the left side.

In the case of replacing the 4 flashers, the resistance Ref. 42980 must be used, but if only two are replaced, the resistance Ref.

58730 must be used. Identify the relay of intermittency of the motorcycle (location and number of pins) and replace it with the one that corresponds to the list that Puig offers.

In the market, there are some motorcycles that do not have a specific relay, which makes it impossible to replace them. It should also be taken into account that if more than one relay intervenes in the blinking action, replacing only one will not solve the problem.

Bike Fitment:

  • SUZUKI DL1000 V-STROM 2014
  • SUZUKI DL1000 V-STROM 2015
  • SUZUKI DL1000 V-STROM 2016
  • SUZUKI DL650 V-STROM 2012
  • SUZUKI DL650 V-STROM 2013
  • SUZUKI DL650 V-STROM 2014
  • SUZUKI DL650 V-STROM 2015
  • SUZUKI DL650 V-STROM 2016
  • SUZUKI DL650 V-STROM 2017
  • SUZUKI DL650 V-STROM 2018
  • SUZUKI DL650XT V-STROM 2015
  • SUZUKI DL650XT V-STROM 2016
  • SUZUKI GSF1200 BANDIT 2001
  • SUZUKI GSF1200 BANDIT 2002
  • SUZUKI GSF1200 BANDIT 2003
  • SUZUKI GSF1200 BANDIT 2004
  • SUZUKI GSF1200 BANDIT 2005
  • SUZUKI GSF1200 BANDIT 2006
  • SUZUKI GSF1250S BANDIT 2007
  • SUZUKI GSF1250S BANDIT 2008
  • SUZUKI GSF1250S BANDIT 2009
  • SUZUKI GSF1250S BANDIT 2010
  • SUZUKI GSF1250S BANDIT 2011
  • SUZUKI GSF1250S BANDIT 2012
  • SUZUKI GSF1250S BANDIT 2013
  • SUZUKI GSF600 BANDIT 2000
  • SUZUKI GSF600 BANDIT 2001
  • SUZUKI GSF600 BANDIT 2002
  • SUZUKI GSF600 BANDIT 2003
  • SUZUKI GSF600 BANDIT 2004
  • SUZUKI GSF650 BANDIT 2005
  • SUZUKI GSF650 BANDIT 2006
  • SUZUKI GSF650 BANDIT 2007
  • SUZUKI GSF650 BANDIT 2008
  • SUZUKI GSF650 BANDIT 2009
  • SUZUKI GSF650 BANDIT 2010
  • SUZUKI GSF650 BANDIT 2011
  • SUZUKI GSF650 BANDIT ABS 2005
  • SUZUKI GSF650 BANDIT ABS 2006
  • SUZUKI GSF650S BANDIT 2005
  • SUZUKI GSF650S BANDIT 2006
  • SUZUKI GSF650S BANDIT 2009
  • SUZUKI GSF650S BANDIT 2010
  • SUZUKI GSF650S BANDIT 2011
  • SUZUKI GSF650S BANDIT 2012
  • SUZUKI GSF650S BANDIT 2013
  • SUZUKI GSF650S BANDIT 2014
  • SUZUKI GSF650S Bandit ABS 2005
  • SUZUKI GSF650S Bandit ABS 2006
  • SUZUKI GSR750 2011
  • SUZUKI GSR750 2012
  • SUZUKI GSR750 2013
  • SUZUKI GSR750 2014
  • SUZUKI GSR750 2015
  • SUZUKI GSR750 2016
  • SUZUKI GSX-R1000 2001
  • SUZUKI GSX-R1000 2002
  • SUZUKI GSX-R1000 2003
  • SUZUKI GSX-R1000 2004
  • SUZUKI GSX-R600 2001
  • SUZUKI GSX-R600 2002
  • SUZUKI GSX-R600 2003
  • SUZUKI GSX-R600 2004
  • SUZUKI GSX-R600 2005
  • SUZUKI GSX-R750 2001
  • SUZUKI GSX-R750 2002
  • SUZUKI GSX-R750 2003
  • SUZUKI GSX-R750 2004
  • SUZUKI GSX-R750 2005
  • SUZUKI GSX-S1000 2015
  • SUZUKI GSX-S1000 2016
  • SUZUKI GSX-S1000 2017
  • SUZUKI GSX-S1000F 2015
  • SUZUKI GSX-S1000F 2016
  • SUZUKI GSX1250F 2010
  • SUZUKI GSX1250F 2011
  • SUZUKI GSX1250F 2012
  • SUZUKI GSX1250F 2013
  • SUZUKI GSX1250F 2014
  • SUZUKI GSX1250F 2015
  • SUZUKI GSX1250F 2016
  • SUZUKI GSX650F 2008
  • SUZUKI GSX650F 2009
  • SUZUKI GSX650F 2010
  • SUZUKI GSX650F 2011
  • SUZUKI GSX650F 2012
  • SUZUKI GSX650F 2013
  • SUZUKI GSX650F 2014
  • SUZUKI GSX650F 2015
  • SUZUKI GSX650F 2016
  • SUZUKI SFV650 GLADIUS 2009
  • SUZUKI SFV650 GLADIUS 2010
  • SUZUKI SFV650 GLADIUS 2011
  • SUZUKI SFV650 GLADIUS 2012
  • SUZUKI SFV650 GLADIUS 2013
  • SUZUKI SFV650 GLADIUS 2014
  • SUZUKI SFV650 GLADIUS 2015
  • SUZUKI SV650N 2003
  • SUZUKI SV650N 2004
  • SUZUKI SV650N 2005
  • SUZUKI SV650N 2006
  • SUZUKI SV650S 2003
  • SUZUKI SV650S 2004
  • SUZUKI SV650S 2005
  • SUZUKI SV650S 2006

Where Can I Buy This Item In Australia?

If you’d like to buy this product as a customer, please visit our retailers page to find a stockist near you.

Alternatively, contact us and we can assist further.


RRP (For Retailers) $41.95
Barcode # 4488000000750
Brand Puig
